Nexo PS 8 Mid-Range Loudspeaker
Nexo PS 8 Mid-Range Loudspeaker is a loudspeaker that can produce 135dB peak SPL. It features Nexo-designed low magnetic emission Neodymium drivers. This makes the unit lightweight and compact. The drivers make it possible for you to use the PS8 next to the magnetically sensitive video and computer equipment.
Flexible coverage patterns are due in part to Nexo’s constant directivity asymmetrical dispersion horn behind the grille. The horn is easily configurable and can be set in four positions by 90-degree rotations.
A single Ps8 speaker has the proper architecture and weight. This balances to act as both a PA and stage monitor. It features a 2-way passive 8Ω design. It uses a single amp channel to deliver bi-amped performance, reducing system cost, size and complexity.
Nexo PS 8 Mid-Range Specifications
| Frequency Response [a] | 69Hz-19kHz±3dB |
| Usable Range @-6dB [a] | 62Hz–20kHz |
| Sensitivity 1W @ 1m [b] | 96 dB SPL Nominal – 94 dB SPL Wideband |
| Nominal Peak SPL@1m [b] | 122 to 125dB Peak |
| HF Dispersion [c] | 50° to 100° Hor. x 55° Vert. Rotatable Horn, 4 positions |
| Directivity | Q : 10 Nominal DI : 10 dB Nominal ( f > 1.8 kHz ) |
| Crossover Frequencies | 2.5 kHz Passive |
| Nominal Impedance | 8Ω |
| Recommended Amplifiers | 200 to 500 W / 8Ω |
Nexo PS 8 Mid-Range Loudspeaker
FEATURES
| Components | LF 1 x 8” (20 cm) Neodymium 8Ω driver |
| HF 1 x 1” Neodymium throat driver + Low Distortion, | |
| Constant Directivity Asymmetrical Dispersion Horn | |
| Height x Width x Depth | 406mm x 250mm x 219 mm |
| (16” x 9 7/8” x 5 5/8”) | |
| Weight | 7.5 kg (16.5 lbs.) |
| Connectors | 2 x NL4MP Speaker 4 pole |
| Construction | Baltic Birch Ply finished with textured black coating |
| Fittings | Molded dark grey metal grill |
| Flying points and fixed installation threaded inserts are fitted | |
| as standard to all cabinet surfaces for connection | |
| of mounting accessories | |
| Stand fittings | Built-in Stand Fitting, (35mm / 1 3/8”) |
